| Pump Speed (Stroke/Min) | Liner size (mm) and Pressure Rating (Mpa) | ||||||||
| Φ100 | Φ110 | Φ120 | Φ130 | Φ140 | Φ150 | Φ160 | Φ170 | Φ180 | |
| 35 | 33 | 27.7 | 23.6 | 20.3 | 17.7 | 15.6 | 13.8 | 12.3 | |
| Displacement (L/S) | |||||||||
| 130 | 13.93 | 16.86 | 20.06 | 23.54 | 27.3 | 31.34 | 35.66 | 40.26 | 45.13 |
| 120 | 12.86 | 15.56 | 18.52 | 21.73 | 25.2 | 28.93 | 32.92 | 37.16 | 41.66 |
| 110 | 11.79 | 14.26 | 16.97 | 19.92 | 23.1 | 26.52 | 30.17 | 34.06 | 38.19 |
| 100 | 10.72 | 12.97 | 15.43 | 18.11 | 21 | 24.11 | 27.43 | 30.97 | 34.72 |
| 90 | 9.64 | 11.67 | 13.89 | 16.3 | 18.9 | 21.7 | 24.69 | 27.87 | 31.25 |
| Basedon100%volumetricefficiencyand90%mechanicalefficiency | |||||||||
