| Pump Speed (Stroke/Min) | Liner size (mm) | |||||||
| Φ100 | Φ110 | Φ120 | Φ130 | Φ140 | Φ150 | Φ160 | Φ170 | |
| Displacement (L/S) | ||||||||
| 120 | 8.48 | 10.26 | 12.21 | 14.33 | 16.62 | 19.08 | 21.70 | 24.50 |
| 110 | 7.77 | 9.40 | 11.19 | 13.13 | 15.23 | 17.49 | 19.90 | 22.46 |
| 100 | 7.07 | 8.55 | 10.17 | 11.94 | 13.85 | 15.90 | 18.09 | 20.42 |
| Pump Pressure (Mpa) | 35 | 29.6 | 24.9 | 21.2 | 18.3 | 16 | 14 | 12 |
| Basedon100%volumetricefficiencyand90%mechanicalefficiency | ||||||||
