Structure
Inner liner: Ultra-High Molecular Weight Polyethylene.
Inner layer: Polymer Synthetic Rubber.
Reinforcement layer: High-Strength Steel Wire Rope.
Outer layer: High-Strength Wear-Resistant Synthetic Rubber.
Features
Application: The fracking hose is utilized for rapid connectionbetween the fracturing wellhead and the manifold skid, or betweenthe fracturing truck and the high- and low-pressure manifolds. Itdelivers a high-velocity mixture of fracturing fluid, proppant, and aciddownhole to induce fractures in the reservoir rock, which are thenpropped open to create stable, long-term flow channels. This processfacilitates the effective release and enhanced recovery of deep oil andnatural gas.
Cost savings: Streamlined components enable quick connection, speedup installation and reduce downtime.Flexible and lightweight: lighter than traditional flow iron and moreflexible.
Fluid to be transfer : Fracturing fluid, fracturing sand, HCl, liquid CO2,etc.
Temperature:-35°C ~ 100°C.
Connection options: Hammer union or flange.
